Operational Amplifier
All series operational amplifier selection guide
All series operational amplifier selection guide
| P/N | channel | Power Supply(V) | GBW(MHz) | Slew Rate(V/μs) | Iq/CH(μA) | Input Bias Current(pA) |
Maximun Vos(mV) |
Noise @ 1KHz Typ(nV/ √ Hz) | Enable Pin | Rail to Rail Input/Output | Package |
| VM9042 | 2 | 3-40 | 25 | 8 | 750 | ±0.5 | ±0.5 | 17 | N | Y/Y | SOP8 |
| VM9044 | 4 | 3-40 | 25 | 8 | 750 | ±0.5 | ±0.5 | 17 | N | Y/Y | QFN16 |
| VM9062 | 2 | 1.5-5.5 | 25 | 8 | 400 | ±0.5 | ±0.5 | 17 | N | Y/Y | SOP8 |
| VM9064 | 4 | 1.5-5.5 | 25 | 8 | 400 | ±0.5 | ±0.5 | 17 | N | Y/Y | QFN16 |
| VM9072 | 2 | 1.5-5.5 | 2.5 | 0.8 | 50 | ±0.5 | ±0.5 | 31 | N | Y/Y | SOP8 |
| VM9074 | 4 | 1.5-5.5 | 2.5 | 0.8 | 50 | ±0.5 | ±0.5 | 31 | N | Y/Y | QFN16 |
